POWER INPUT, CW: 3000 watts maximum
FREQUENCY RESPONSE: 10 kHz-100 MHz
INPUT IMPEDANCE: 50 ohms
VSWR: 2.0:1 max, 10 kHz-100 MHz;
6:1 max, 10-20kHz above 1kW input power
ELECTRIC FIELD INTENSITY: See Figure 1
RF INPUT CONNECTOR: See Model Configurations
COOLING: Natural convection to 40˚ ambient temperature
WEIGHT: 95 kg, 210 lb
SIZE (W x H x D maximum): 265 x 240 x 120 cm, 105 x 96 x 49 in
SIZE (W x H x D minimum): 265 x 206 x 120 cm, 105 x 81 x 49 in
EXPORT CLASSIFICATION: EAR99
