Frequency Range …………………………………………………. 10 kHz–100 MHz
Input Impedance ………………………………………………….. 50 ohms
VSWR ………………………………………………………………… 2.5:1 maximum (1.4:1 typical)
Power Handling …………………………………………………… 500 watts maximum
Field Intensity (in defined test volume)
Between Type A elements …………………………………. Nominally 350 V/m with 500 W input
Between Type B elements …………………………………. Nominally 200 V/m with 500 W input
Maximum Test Object Volume
Between Type A elements …………………………………. 36 x 46 x 36 cm (14 x 18 x 14 in)
Between Type B elements …………………………………. 48 x 46 x 36 cm (19 x 18 x 14 in)
Size
With Type A elements ……………………………………… 74 x 41 x 102 cm (29 x 16 x 40 in) maximum
With Type B elements ……………………………………… 104 x 41 x 102 cm (41 x 16 x 40 in) maximum
Connector ………………………………………………………….. Type N female
Weight ………………………………………………………………. 13 kg (28 lb) maximum
